GeoCool 36K Vertical Right Return Heat Pump - 230v

Sandra
Updated

GCHPV036TGTANXR

NON DIY - Licensed HVAC Installation



Description

The 3-ton, two-stage unit offers powerful performance and dependable comfort for spaces up to 1,500 sq. ft. Operating on 230 volts, single-phase, 60 Hz, it features a durable scroll compressor motor and a 3/4 HP Axial Flux (No Shaft) BLA blower motor for efficient, quiet air distribution.

Using R-410A refrigerant, the unit includes a replaceable 28x30 filter and comes in a neutral gray finish to suit most indoor environments. It meets key efficiency and safety standards, being ETL listed, AHRI certified, ENERGY STAR compliant, and ENERGY STAR certified.

The electrical specifications include a maximum fuse breaker rating of 42.1 amps and a minimum circuit ampacity of 26.4 amps. The unit's dimensions are 32" deep, 44" high, and 25.75" wide, with a net weight of 315 lbs.

It includes built-in electronics and contains chemicals, aerosols, and compressed gas, and carries a Proposition 65 warning. The system is backed by a 10-year registered parts limited warranty, 10-year compressor warranty, and a 5-year base parts warranty for peace of mind.

Find the Brochure HERE

─────────────────────────────────────────────────────────────

Key Specs  (Performance Specs Click Here)

  • Qualifies for federal tax credit and incentives

  • Highest energy efficiency in its class

  • Safety high/low pressure switches

  • Quiet operation

  • Sinusoidal motor control technology

  • Insulated sloped stainless steel drain pan

  • Advanced control board with diagnostic LEDs

  • Double O-ring water connections

  • Optional domestic water pre-heating

  • Made in the USA

  • 10-year compressor warranty

─────────────────────────────────────────────────────────────

Warranty

The MRCOOL warranty provides comprehensive coverage for your unit when installed by a licensed Professional

─────────────────────────────────────────────────────────────
