GeoCool 36K Horizontal Right Return Heat Pump - 230v

Sandra
Updated

GCHPH036TGTANXR

NON DIY - Licensed HVAC Installation



Description

This 3-ton, two-stage system is designed for spaces up to 1,500 sq. ft. and features a powerful scroll compressor and a 3/4 HP Axial Flux (No Shaft) BLA blower motor. It operates on 230 volts, single-phase, 60 Hz electrical service for dependable performance.

The unit utilizes R-410A refrigerant and includes replaceable 20x37 filters for easy upkeep. Finished in a sleek gray color, it is ETL listed, AHRI certified, and meets ENERGY STAR standards, ensuring energy-efficient operation.

Key electrical specs include a maximum fuse breaker of 42.1 amps and minimum circuit ampacity of 26.4 amps. The unit measures 51" deep, 23.13" high, and 25.75" wide, with a net weight of 330 lbs.

This unit contains electronics, chemicals, aerosols, and compressed gas, and carries a Proposition 65 warning. It is backed by a 10-year registered parts limited warranty and a 10-year compressor warranty, with a 5-year limited base warranty.

Find the Brochure Here

─────────────────────────────────────────────────────────────

Key Specs  (Performance Specs Click Here)

  • Qualifies for federal tax credit, and other incentives

  • Highest energy efficiency in its class

  • Safety high and low pressure switches

  • Quiet operation

  • Full-featured sinusoidal EON motor control technology

  • Insulated sloped stainless steel drain pan

  • Advanced unit control board with diagnostic LEDs

  • Double O-ring water connections

  • Easy service access

  • Optional domestic water pre-heating

  • Made in the USA

  • 10-year compressor warranty

─────────────────────────────────────────────────────────────

Warranty

The MRCOOL warranty provides comprehensive coverage for your unit when installed by a licensed Professional

─────────────────────────────────────────────────────────────
